预加张力对电容薄膜真空计感压膜片变形的影响

孟岳; 陈叔平; 成永军; 孙雯君; 裴晓强; 贾春旺; 白彪坤; 金树峰

doi:10.3969/j.issn.1006-7086.2020.01.005

预加张力对电容薄膜真空计感压膜片变形的影响

1. 兰州理工大学石油化工学院, 兰州 730050;
2. 兰州空间技术物理研究所, 兰州 730000

详细信息

作者简介:
孟岳(1993-),男,河南孟津人,硕士研究生,主要从事真空低温技术领域的研究。E-mail:mengyue1004@126.com。

通讯作者:
陈叔平(1964-),男,浙江新昌人,教授,主要从事真空低温技术领域的研究。E-mail:chensp@lut.cn。

中图分类号: TB771
计量
- 文章访问数: 12
- HTML全文浏览量: 0
- PDF下载量: 8
出版历程
- 收稿日期: 2019-11-10
- 网络出版日期: 2023-07-05

Effect of Pre-Tension on Deformation of Capacitive Diaphragm Vacuum Gauge

1. College of Petrochemical Engineering, Lanzhou University of Technology, Lanzhou 730050, China;
2. Lanzhou Institute of Physics, Lanzhou 730000, China

摘要

摘要: 预加张力对电容薄膜真空计感压膜片变形的影响
- 电容薄膜真空计 ;
- 感压膜片 ;
- 预加张力 ;
- 挠度特性
Abstract: According to the uniform load-deflection behavior of the pressure sensing diaphragm of capacitive diaphragm vacuum gauge under pre-tension conditions, Von Karman equation and the Beams equation are selected as the theoretical model of the pressure sensing diaphragm. And the nonlinear finite element simulation analysis is carried out in combination with the static module in ANSYS Workbench software. The results show that the pre-tension has a significant effect on the deflection of the pressure sensing diaphragm. The deflection of the diaphragm decreases with the increase of the pre-tension. With the increase of the uniform load and the pre-tension, the decrease of deflection of the pressure sensing diaphragm is weakened. Under the same uniform load, the greater the pre-tension, the greater the influence ratio. When the uniform load increases and the deflection of the pressure sensing diaphragm increases, the deflection caused by the pre-tension is decreasing, and the influence ratio is gradually decreased. When the pressure sensing diaphragm is initially deformed by the 1 Pa uniform load, the pre-tension of 13 MPa has a 93% influence on the deflection of the diaphragm; when the uniform load exceeds 800 Pa, the deflection caused by the pre-tension is less than 35% of the deflection of the entire pressure sensing diaphragm; The uniform load is 1 000 Pa, and the pre-stress is 7 MPa, the influence ratio is 17.9%. The simulation results are verified by using the real capacitive diaphragm vacuum gauge.
- capacitive diaphragm vacuum gauge /
- pressure sensing diaphragm /
- pre-tension /
- deflection behavior

HTML全文

参考文献(11)

[1]	卢耀文,陈旭,李得天,等.便携式真空计校准装置[J].真空科学与技术学报, 2013, 33(5):462-467.
[2]	王凡,崔宏敏,宗义仲,等.电容式薄膜真空压力传感器设计[J].传感器与微系统, 2017, 36(3):84-86, 90.
[3]	杨春林,闫金锁.数字式电容薄膜绝对压力变送器的设计研发[J].真空, 2017, 54(5):19-21.
[4]	丁基敏.电容薄膜式绝对压力变送器的发展[J].真空, 2001,38(4):8-10.
[5]	李得天,孙雯君,成永军,等. MEMS型电容薄膜真空计研究进展[J].真空与低温, 2017, 23(2):63-67.
[6]	李琦,冯驹先,董中林,等.适应复杂环境的真空计[J].真空科学与技术学报, 2016, 36(11):1316-1319.
[7]	NALLATHAMBI A, SHANMUGANANTHAM T. Design of Diaphragm Based MEMS Pressure Sensor with Sensitivity Analysis for Environmental Applications[J]. Sensors&Transducers, 2015, 188(5):48.
[8]	BISWAS P V, KIM H Y, AHN J H. The effect on deflection of steel diaphragm of pressure sensor due to change in boundary condition in the welded region[J]. Journal of Mechanical Science and Technology, 2017, 31(4):1921-1925.
[9]	徐芝纶.弹性力学[M].下册.北京:高等教育出版社, 2006.
[10]	BEAMS J W.The structure and properties of thin film[M]. New York Wiley and Sons, 1959.
[11]	孙雯君,冯焱,马奔,等.小型电容薄膜真空规的设计[J].真空与低温, 2012, 18(4):232-234.
