小型混合工质氮气液化器

郭浩; 公茂琼

doi:10.3969/j.issn.1006-7086.2020.03.010

小型混合工质氮气液化器

郭浩¹,
公茂琼^1,2

1. 中国科学院理化技术研究所低温与制冷研究中心, 北京 100190;
2. 中国科学院大学, 北京 100049

基金项目:

国家自然科学基金（51625603）

详细信息

作者简介:
郭浩,博士研究生,主要从事深冷混合工质节流制冷技术及应用、气体液化技术及装置研发、大温跨混合工质热泵及工质热物性等研究。E-mail:hguo@mail.ipc.ac.cn。

中图分类号: TB657.8
计量
- 文章访问数: 17
- HTML全文浏览量: 1
- PDF下载量: 7
出版历程
- 收稿日期: 2019-11-17
- 网络出版日期: 2023-07-05

Miniature Nitrogen Liquefiers Based on Low-temperature Mixture Refrigerator

GUO Hao¹,
GONG Maoqiong^1,2

1. Research center for cryogenics and refrigeration, Technical Institute of Physics and Chemistry Technology, Chinese Academy of Sciences, Beijing 100190, China;
2. University of Chinese Academy of Sciences, Beijing 100049, China

摘要

摘要: 小型氮气液化器具有经济性、便携性，可满足偏远地区或野外环境以及科研实验室的小用量液氮供应。以深冷混合工质节流制冷循环为基础构建了一种氮气液化循环，采用遗传算法结合MATLAB和ASPEN HYSYS对该循环进行优化，并开展了实验验证装置的研制和测试。实验结果表明，该氮气液化器的比功耗为1.02 kW·h/L，加上PSA制氮机，整个设备能耗为1.77 kW·h/L。同时成功研制了5～10 L/h系列微小型氮气液化器，可满足客户对不同液氮量的需求；与现有商用氮气液化器相比，该氮气液化器在比功耗、成本和可靠性等方面具有明显的优势。
- 氮气液化器 ;
- 混合工质 ;
- 节流制冷机
Abstract: The miniature nitrogen liquefier can meet the requirements of small amount of liquid nitrogen supply in remote areas,field environment,and scientific research laboratories.A nitrogen liquefaction cycle based on low-temperature mixture refrigerator cycle was built and optimized using the genetic algorithm combined with MATLAB and ASPEN HYSYS.And an experiment device was developed and test.The experimental results show that specific power consumption of the nitrogen liquefier is 1.02 kW·h/Land considering the PSA nitrogen generator,that of the entire device is 1.77 kW·h/L.The series of miniature nitrogen liquefiers can achieve the capacity of 5~10 L/h,and can also be customized according to specific needs.Compared with the commercial nitrogen liquefiers,the liquefiers have obvious advantages of low specific power consumption,low cost and high reliability.
- nitrogen liquefier /
- mixed-refrigerants /
- throttle refrigerator

HTML全文

参考文献(25)

[1]	Cryogenic nitrogen generators[EB/OL].[2019-01-10]. http://www.imtekcryogenics.com.
[2]	Liquid nitrogen generators[EB/OL].[2019-01-10]. http://www.cryoindustries.com.
[3]	Liquid nitrogen plants[EB/OL].[2019-01-10]. http://www.cryomech.com..
[4]	Liquid nitrogen system[EB/OL].[2019-01-10]. http://www.stirlingcryogenics.com.
[5]	BOYARSKII M Y,LUNIN A I,MOGORYCHNYI V I.Characteristics of Cryogenic Systems Operating on Mixtures[J].Mini,1990.
[6]	GONG M Q,LUO E C,WU J F,et al.On the temperature distribution in the counter flow heat exchanger with multicomponent non-azeotropic mixtures[J].Cryogenics,2002,42(12):795-804.
[7]	LEROU P M,VEENSTRA T T,BURGER J F,et al.Optimization of counter flow heat exchanger geometry through minimization of entropy generation[J].Cryogenics,2005,45:659-69.
[8]	GONG M Q,WU J F,LUO E R,et al.Study of the single-stage mixed-gases refrigeration cycle for cooling temperature-distributed heat loads[J].International Journal of Thermal Sciences,2004,43(1):31-41.
[9]	REMELJEJ C W,HOADLEY A F A,An exergy analysis of small-scale liquefied natural gas (LNG) liquefaction processes[J].Energy,2006, 31(12):2005-2019.
[10]	ARKHAROV A M,ARKHAROV I A,Analysis of existing small-capacity plants for natural-gas liquefaction[J].Chem Petrol Eng,2010,46(7/8):397-416.
[11]	CAO W S,LU X S,LIN W S,et al.Parameter comparison of two small-scale natural gas liquefaction processes in skidmounted packages[J].Appl Therm Eng,2006,26:898-904.
[12]	KOUNTZ K,KRIHA K,LISS W,et al,Development of a small-scale natural gas liquefier[R].Final Report GTI Project65943,Gas Technology Institute,2003.
[13]	NEKSA P,BRENDENG E.Small scale natural gas liquefaction plants[C]//In:Proceedings of International Congress of Refrigeration,Beijing,2007.
[14]	NEKSA P,BRENDENG E,DRESCHER M,et al.Development and analysis of a natural gas reliquefaction plant for small gas carriers[J].J Nat Gas Sci Eng,2010,2(2):143-149.
[15]	GONG M Q,WU J F,SUN Z H,et al.Development and performance test of a small trailer-mounted moveable natural gas liquefier[J].Energy Conversion and Management,2012,57:148-153.
[16]	VENKATARATHNAM G.Cooling and liquefaction of air and its constituents[C]//Cryogenic Mixed Refrigerant Process,Springer,2008:221-249.
[17]	BOIARSKII M Y,LUNIN A I,POTAPOV G G,et al.Optimization of parameters of installations with recycle of mixtures for manufacture of liquid nitrogen[J].Chemical and Petroleum Engineering,1993,29:623-630.
[18]	POTAPOV G G,BOYARSKII M Y,LADOKHIN S D.Expermental characteristics of the external mixture cycle of a nitrogen liquefier[J].Chemical and Petroleum Engineering,1995(3):321-324.
[19]	LITTLE W A.Design and operation of an office liquid nitrogen generator[C]//Cryoprague,2006.
[20]	Elan2 Liquid Nitrogen Generators.[EB/OL].[2019-01-10]. http://www.elan2.com.
[21]	WANG H C,GUO H,ZHAO Y X,et al.Development and performance test of a miniature movable mixed refrigerant liquid nitrogen generator[J].Cryogenics,2018,96:1-9.
[22]	SMITH A R,KLOSEK J.A review of air separation technologies and their integration with energy conversion processes[J].Fuel Processing Technology,2001,70:115-134.
[23]	RICHARD W B.Future directions of membrane gas separation technology[J].Industrial&Engineering Chemistry Research,2002,41(6):1393-1411.
[24]	GONG M Q,LUO E C,WU J F.Principles and applications on mixed-gases Joule-thomson refrigeration at low temperature range[C]//China Science and Technology Press,Bejing,2014:28-66.
[25]	PENG D Y,ROBINSON D B.A new two-constant equation of state[J].Ind Eng Chem Fundam,1976,15:59-64.
